Yamamura Churchill J
http://www.my-hiend.com/leoyeh2/2014a/daily001662.jpg
Wilson Benesch unveils 25th anniversary Circle 25 turntable
http://my-hiend.com/audiotemp/2014/N...day/2.26.1.jpg
Wilson Benesch發表25周年紀念黑膠轉盤 "Circle 25 Turntable"，售價約為1750英鎊，搭配ACT 05唱臂售價則為3345英鎊。其引用過去在1989年推出的Analogue Collection的經典圓形轉盤設計，並有一個25周年的銘牌。
照片中為白色，另外也將提供黑色版本。轉盤的底座是由Delrin製成，一種高質量的聚合物，增加了兩公斤的重量和優良的阻尼特性。
http://my-hiend.com/audiotemp/2014/N...day/2.26.2.jpg
http://my-hiend.com/audiotemp/2014/N...day/2.26.3.jpg
http://wilson-benesch.com/
撿日不如撞日。這句俗語用在去舊貨店找二手唱片真是再貼切不過了。昨晚，送女兒去管弦樂團團練，順便繞去附近的Goodwill看看最近又有什麼新到的二手唱片。一個半小時之後，抱了50張唱片出來。
這是其中的幾張
http://www.my-hiend.com/vbb/attachme...4&d=1393556530
顯然，最近有位披頭四迷捐了不少唱片;) 運氣不錯，我大概翻了一個鐘頭後，旁邊來了另一位先生，也開始一疊一疊唱片在那翻。上次去也有競爭者。看來，這一帶聽唱片的人還不少。喔！一張唱片1.59美元再加6%的稅。昨晚買一整疊，大概還不夠在ebay上買一張稍微搶手些的唱片(giggle)
Thales發表新唱臂"EASY"
瑞士的Thales設計了一款新的高性能唱臂，而且價格非常具有競爭力，C/P值很高的"EASY"，Thales認為消費者將可在這個價格得到過去不可能得到的音樂體驗。
The clever arrangement of six bearing points creates three null points for the horizontal tracking error, plus a zero point for the variable offset angle as well, which is a really novel for a tonearm design.
意味唱頭有一個良好的跟蹤引導，大幅減少側向力，使得資訊的讀取更清楚。
Spindle to Pivot 230mm (EMT/Ortofon standard)
Effective length: 220mm
Effective mass: 10gm
Max. tracking error: ±0,4° (trad. 9“ tonearm: 2,2°)
Max. offset angle: ±12° (trad. 9“ tonearm: 23°)
Cartridge weight 5g – 20g
Output connection 5-pin-DIN (integrated)
http://my-hiend.com/audiotemp/2014/N...yday/3.6.1.jpg
http://my-hiend.com/audiotemp/2014/N...yday/3.6.2.jpg
http://www.tonarm.ch/
这压环是很实用的道具
http://www.my-hiend.com/leoyeh2/2014a/daily001699.jpg
http://www.sibatech.co.jp/abis/tonearm.html
SA-1
* The major key to tonearm quality is the sensitivity and stability in retrieving delicate signals, for which the bearings are the determining factor. The SA-1 employs miniature radial bearings for both horizontal and vertical movement. Very high performance is achieved at a reasonable price.
* The rectangular arm-wand is machined from a solid aluminum block having an advantage in rich and tight bass reproduction, as bass sound is mainly recorded in the horizontal plane of the groove.
* Tonearm wires run through separate aluminum tubes inside the arm so that stereo separation is maximized.
* Reproduced sound is precise and clean, thanks to hand assembly by highly skilled craftsmen.
* Comes with detachable headshell, phono cable (RCA output plug, or optionally as XLR), screws, washers, wrench and marking pin.
Specifications Length: 310mm Spindle center to arm pivot distance: 212mm Stylus to pivot distance: 228mm Overhang: 16mm Cartridge weight: 15-45 grams, including headshell Net weight: 745g (with headshell attached: 762g)
TA-1
* The major key to tonearm quality is the sensitivity and stability in retrieving delicate signals, for which the bearings are the determining factor. The TA-1 employs a miniature radial bearing for horizontal movement and a miniature pivot bearing for vertical movement. Very high performance is achieved at a reasonable price.
* The body is constructed from a machine-tooled solid aluminum block.
* The hand-assembled arm wand satisfies every vital condition necessary for vibration-free and noise-free reproduction.
* Reproduced sound is precise and clean, thanks to hand assembly by highly skilled craftsmen.
* Comes with detachable headshell, phono cable (RCA output plug, or optionally as XLR), screws, washers, wrench and marking pin.
Specifications Length: 305mm Spindle center to arm pivot distance: 216mm Stylus to pivot distance: 232mm Overhang: 16mm Cartridge weight: 15-29 grams, including headshell Net weight: 580g (with headshell attached: 597g)
Ikeda 9TS
與9系列的聲音特色一樣，不過0.35mVrms的輸出比9TT高出一倍，比較容易搭配，價格也稍低(USD 2,800)
http://www.my-hiend.com/leoyeh2/2014a/daily001702.jpg
Tonally it has the same musicality as the other MC cartridges in the "9"-family. No compromises are made also during processing. The 9TS 0, 35mV is about twice as high output voltage compared to the 9TT so that it can be operated without any problems on cheaper phono preamps.
Output Voltage: 0.35mVrms (1kHz 35.4mm/sec., at 45°peak)
Coil Impedance: 6.0 ohms (1kHz)
Appropriate Stylus Force: 2.0grams ±0.2 grams
Frequency Response: 10Hz ～ 45kHz
Channel Separation: over 27dB (1kHz)
Channel Balance: within 1.0dB (1kHz)
Stylus Chip: Oval-shaped solid Diamond
Cantilever: Double layered duralumin pipe.
Weight: 10 grams
Compliance: 7 x 10-6cm/dyne
Ikeda SAI
來自傳奇的9MUSAM，全新毫不妥協的設計，輸出較原來增加，為0.3 mVrms
http://www.my-hiend.com/leoyeh2/2014a/daily001703.jpg
The "SAI", is the uncompromising advancement of the legendary "9MUSAM" with completely brand new pickup system. Engineers from IKEDA succeeded to transfer the tonal qualities of the 9MUSAM without compromising. The output voltage could be increased through further development in the area of the coil drive to 0, a channel equal 0, 5dB 30mV! The cantilever consists of "Boron" and the diamond is "Micro-Ridge."
MC cartridge: Universal type dedicated to tonearm.
Output Voltage: 0.3 mVrms (1kHz 35.4mm/sec., at 45°peak)
Coil Impedance: 2.5 ohms (1kHz)
Appropriate Stylus Force: 2.0grams ±0.2 grams
Frequency Response: 10Hz ～ 45kHz
Channel Separation: over 30dB (1kHz)
Channel Balance: within 0.5dB (1kHz)
Stylus Chip: Micro-ridge solid Diamond
Cantilever: made of Boron.
Weight: 30 grams
Compliance: 7 x 10-6cm/dyne
SAI的發音念"賽"."塞".但也可以台語發音叫"@#$%&"....昏倒!!引用:
作者: Leo Yeh
來一顆High End的SAI吧~~~~~~~~~~~~
請問站長及先進，
FR唱臂你會推薦什麼品牌唱頭？
池田是否比光悅較好搭配？敬請指教。
感謝。
1.重質量的唱頭,優先為FR7,其次是IKEDA,最後是Ortofon SPU系列.引用:
作者: BBWW
2.沒有誰比較好的問題,是口味是否合乎你的問題!!
第二點真是良言啊！最近看到MyAV有位以前玩的很兇的網兄不玩了，還忠告大家要量力而為。貴的音響／唱片當然極有可能在性能或效果上完全超越我們現有的音響／唱片，可是那真的是合乎我們的口味？還是只是因為別人說好？如果有能力能試試看當然最好，沒能力就算了，反正還有很多別的東西可試可玩。聽音樂玩音響，最有趣的地方就是，不管預算高低，都有得玩。沒什麼錢就聽聽網路收音機，還是一樣可以聽的很開心啊！這是個消遣，拿來比誰強誰弱的遲早會burn－out的。人生苦短，何必跟自己過不去呢？引用:
作者: 將軍
引用:
作者: kevintran
那位不玩了.......?
就那位會癢又要跑操場的啊！引用:
作者: hojuiyang111
Cartridge History
http://www.djsociety.org/Cart.htm
Lumen White Mystere
最高級的氣動式限量版唱盤
http://my-hiend.com/audiotemp/2014/N...day/3.31.1.jpg
具有前所未有的超精密工程水準，真正的平衡頻譜設計、材料、施工，對於最終的訊號保真度。
傳動上是專業、直聯和空氣軸承技術，高扭矩馬達，高達1.2噸的電機旋轉能力消除了"Brake"效應，提供高於傳統皮帶傳動的動態和跟蹤能力及精度。有33和45轉(也可提供78轉或其他規格)。
特製的空氣靜壓軸承，以molecular-mechanics研究的標準是設計和製造的最低要求，保持盤片完全懸浮的零機械接觸。
platter radial run out (spindle centering) and axial run out (planarity) < 1 micron.
唱盤高慣量，共振優化，可變曲線和角度的配合，專有的balanced spectrum alloy。降低寄生共振，能量儲存和延遲影響，不會改變訊號的阻尼技術。
模組化的底盤結構。balanced spectrum合金具有優化的機械接地和震動能量排放設計，設計自由的阻尼化合物，進取合成非自然的光譜材料，達到前所未有、自然發聲的泛音和諧波、瞬變微妙和時間結構的訊息。
擁有專利的"機械二極管"不耦合系統，提供一個主要的單向振動疏散通道。
http://my-hiend.com/audiotemp/2014/N...day/3.31.2.jpg
http://www.lumenwhite.com/mystere_uk.html
The archon© time-aligned moving coil phono cartridge
http://my-hiend.com/audiotemp/2014/N...yday/4.7.7.jpg
The archon©的time-aligned全新設計動圈唱頭。
使用獨特的設計，以Timet-1100固體(一種超高強度的泰坦合金)一體式製成。內部的液體阻尼在某些領域可以為聽者帶來獨特的能量移轉能力如微小的聲音細節。從而豐富並表現很少發掘的諧波和氛圍細微的差別。The archon©提供聲音如現場般的畫面和開闊性，詳細和豐富的諧波結構。自然、豐富多彩的聲音。
http://my-hiend.com/audiotemp/2014/N...yday/4.7.8.jpg
http://my-hiend.com/audiotemp/2014/N...yday/4.7.9.jpg
technical parameters
* 0.5 mV output
* silver coils
* ultra-rigid special dampened titanium "Timet 1100" corpus
* static compliance 17-19 mm/N (18°C to 30°C)
* 16 to 20 mN tracking force range
* 18 mN recommended tracking force
* channel balance better 0.5 dB / at 1 kHz
* channel separation 28 dB *
* frequency response 15 Hz to 32 kHz +/- 2 dB
* Shibata EVO stylus
* internal resistance 8 Ohms
* load resistance 40-1000 Ohms
* cantilever C37-coated tempered aluminum
* cartridge weight only 11.5 grams
猜猜看這張要多少？
http://www.my-hiend.com/leoyeh2/2014a/daily001816.jpg
John Lennon & Yoko Ono: Double Fantasy
Year: 1980
(via nme.com; image via imaginepeace.com)
http://www.whathifi.com/news/10-of-t...ds-of-all-time
過去5年，英國的黑膠唱片銷售成長了270%
https://www.youtube.com/watch?v=Rdn6Yuev7lo
Sales of vinyl records in the UK have increased more than 270% over the past 5 years, according to industry data. The return of 'analogue' and the art form is giving new hope to an embattled music industry. Have you ever bought a vinyl record? What was it?
TechDAS 六月份將開始發售 Air Foece Two唱盤，TDC01 Ti MC唱頭
TechDAS Air Foece Two 定價: 3,300,000 日幣
TDC01 Ti MC 預定售價: 800,000 日幣
http://my-hiend.com/audiotemp/2014/N...day/4.29.1.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.2.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.3.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.4.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.5.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.6.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.7.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.8.jpg
http://my-hiend.com/audiotemp/2014/N...day/4.29.9.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.10.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.11.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.12.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.13.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.14.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.15.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.16.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.17.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.18.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.19.jpg
http://my-hiend.com/audiotemp/2014/N...ay/4.29.20.jpg
這次回台承蒙友站的digifan網兄的好意贈與一套2014高雄音響展的黑膠（還大老遠坐捷運送給我，真是讓我感動不已）
http://img.u-audio.com.tw/showimage.asp?imgid=2073264
這套黑膠還有附一張CD和一張DVD。真的要幫高雄音響展的主辦單位拍手鼓勵一下：製作的非常認真（唱片好安靜，沒有雜音），還加上了每一首曲子錄音現場麥克風的配置圖。讚的啦！
