BSC L5 Three-Chassis Remote Controlled Line Level Preamplifier & BSC S5 Stereo and M5 Mono amplifiers

S5和M5擴大機延續了BSC-60和BSC-100M A類擴大機的成功。這兩款新的擴大機重新定義了標準，成為新的參考系列擴大機。

關於S5，是一部A類放大的立體聲擴大機。單邊在8歐姆的情況下提供80W的推力，建構在1,450 VA的環形變壓器和每聲道超過54,000微法的濾波電容上。
設計上採用雙單聲道設計，由兩個獨立電路和隔離輸出建構。內部有兩個散熱器做冷卻。並且可以切換成約38W的A/B類輸出做低功耗輸出。

關於M5，他不只是更大推力的單聲道擴大機，也擁有更佳的能力。同樣的1,450環形變壓器但配合超過108,000微法的濾波電容。在8歐姆的條件下輸出功率為140W，1歐姆時更可連續輸出1,120W。
M5擁有兩個重新設計過的超安靜環形變壓器，耦合一個高電流和兩個穩壓電源供應器。第二個變壓器被設計用在較低層次的電路上。M5的線路路徑簡短並經過優化。所有組件都通過軍用標準。
為了排散A類140W擴大時產生的熱量，內部安裝四個散熱器來冷卻輸出裝置。使用者也可切換成63W的A/B類輸出模式達到低耗能的方式。


BSC L5 Preamplifier


BSC L5 Preamplifier


BSC L5 Preamplifier


BSC L5 Preamplifier







M5 Specifications

Output power: 140 Watts into 8 ohms, 280 watts into 4 ohms, 560 watts into 2 ohms, 1120 watts into 1 ohm
Output Impedance: < 0.12 ohms at 20 Hz to 20 kHz
Gain: 27.5 dB
Input Impedance: 48K Balanced via XLR connector, 20K single ended via RCA connector
Input sensitivity: 1.35V rms Balanced or Single ended
Frequency response: 20 Hz to 20 kHz +/- .25 dB
Total Harmonic Distortion: <0.065% at 20Hz to 1kHz, <.58% at 10K, <1.8% at 20K at 135 Watt output 8 ohms
Signal-to-noise: > 106.5 dB, unweighted, > 116.5 dB, "A"-weighted, 135 W, 8 Ohms
Power consumption: Stand by Mode < 2 Watts, Idle: 800 W, Maximum: 1500 W
External Chassis top temperature: < 58° C, 136° F at 100% Bias
Inputs: 1 single-ended via RCA connector, 1 balanced via XLR connector
Outputs: 1 pair custom designed gold plated binding posts .25", 6.4 mm spade terminal width
Dimensions: 16.5 in. W x 10.87 in. H x 20.75 in. D
419.1 mm W x 276.1 mm H x 527 mm D
Weight: In shipping carton: 00 lb, 00.00 kg
Unit Only - 125 lb, 56.70 kg

S5 Specifications

Output power: 75 Watts into 8 ohms, 150 watts into 4 ohms, 300 watts into 2 ohms, 600 watts into 1 ohm both channels driven
Output Impedance: < .17 ohms at 20 Hz to 20 kHz
Gain: 24.3 dB
Input Impedance: 48K Balanced via XLR connector, 20K single ended via RCA connector
Input sensitivity: 1.35V rms Balanced or Single ended
Frequency response: 20 Hz to 20 kHz +/- .25 dB
Total Harmonic Distortion: <0.00% at 20Hz to 1kHz, <.0% at 10K, <0.0% at 20K at 75 Watt output 8 ohms
Signal-to-noise: >000.0 dB, unweighted, >000.0 dB, "A"-weighted, 75 W, 8 Ohms
Power consumption: Stand by Mode < 2 Watts, Idle: 700 W, Maximum: 1500 W
External Chassis top temperature: < 00° C, 000° F at 100% Bias
Inputs: 2 single-ended via RCA connector, 2 balanced via XLR connector
Outputs: 2 pair custom designed gold plated binding posts .25", 6.4 mm spade terminal width
Dimensions: 16.5 in. W x 10.87 in. H x 20.75 in. D
419.1 mm W x 276.1 mm H x 527 mm D
Weight: In shipping carton: 00 lb, 00.00 kg
Unit Only - 00 lb, 00.00 kg
