Electrocompaniet PD 1 DAC
http://www.my-hiend.com/leoyeh/2010b/168-dac_2.jpg
As the major general in the use of computers and iPods as storage medium for music, think Electrocompaniet sound deserves a bit more - their solution is called PD 1 DAC.
In the 37 years Electrocompaniet has existed, those that most people already know, produced amplifiers and CD players and other devices for playback of music, and it is the experience Electrocompaniet claimed to have "built" into their new DAC.
PD 1 DAC handles all popular digital input signals from PC to portable MP3 players to TVs and CD players, and there are 5 inputs of exercises which can be either wireless, optical, coaxial, or USB. Wireless use is only possible via additional module in the form of a USB adapter, which in turn makes it possible to download music directly from the PC and even through the remote control, controlling basic functions such as back and forth on the PC, and audio volume and input selection.
PD 1 DAC signal processing of all digital inputs should lift the sound to new heights, and disseminate the music dynamic, open and rich in detail.
Specifikationer:
Specifications:
- Channels: 2
- Output impedance: 100 ohms
- Output Level: 3.4 Vrms
- Noise Ratio (20 - 20 kHz): <- 140 dB
Frekvensrespons: 1 – 48 kHz
Frequency response: 1 - 48 kHz- THD + N: <0,003%
- DAC resolution: 192 kHz, 24bit
- Digital / Analog Conversion: 192 kHz, 24bit
- Outputs: unbalanced RCA / phono and balanced XLR
- Weight: 4.3 kg.
Supported sampling rate:
- SPDIF 192 kHz, 24 bit
- USB 48 kHz, 16 bit
- RF Link 48 kHz, 16 bit
Digital inputs:
- 2 x SPDIF Coax
- 1 x SPDIF TOSlink
- 1 x USB Type B
- 1x RF
www.electrocompaniet.no
